MERO2 High-end in-wall speaker 2"


High-end in-wall speaker 2"

The MERO speakers will blend beautifully into any interior due to their nearly invisible design making only their extraordinary sound draw your attention. Their slim grill with very thin border of only 1 mm and limited grill depth extrudes the surface by only 3.2 mm when installed. The Ultra-compact size enables the MERO2 smoothly integrate into any interior like no other loudspeaker. The outer dimensions only measure only 146 x 98 mm and the built-in depth which doesn’t exceed 70 mm allows installation in any surface while being unobtrusive. The sound originates from a 2” aluminum cone driver which provides a full-range, warm and detailed sound, with an improved response in the low frequencies due to a ported enclosure with closed back can. This way, a smooth sound reproduction with clear and crisp sound is guaranteed. An internal self-resetting network provides an optimal overload protection. All these details share their part to the quality of the MERO 2, resulting in a highly reliable loudspeaker producing a pure sound with a maximum power handling of 20 Watt and an RMS power handling of 10 Watt. An elegant look with minimal visual impact is created by the slim grill with very thin border, while lifetime stability, secure mounting and easy installation is guaranteed using the quick-fix mechanism which can be tightened by two screws and the Gold-Con™ spring clamp connectors. The grill is held in place using neodymium magnets, providing a quick and reliable assembly. Installation can be done both vertically and horizontally.


Would you like a Demo?
  • 2" full range aluminum driver
  • SlimLine™ grill with 1mm thin border
  • QuickFix installation system
  • Gold-Con™ spring clamps

8 ohm  16 ohm

Speaker type : Full range
Max. Power : 20 W
RMS Power : 10 W
Sensitivity (1W/1m) : 83 dB
Sound Pressure (Max. W/1m) : 93 dB
Frequency Response (± 3 dB) : 120 Hz - 20 kHz
Frequency Range (-10 dB) : 100 Hz - 20 kHz
Dispersion Horizontal : 165°
Dispersion Vertical : 165°
Connectors : Gold-Con™ spring clamps
Drivers : 2” Aluminium membrane (coaxial)
Impedance : 16 Ω (MERO2D)
Impedance : 8 Ω (MERO2)
Dimensions : 146 x 98 x 70 mm (W x H x D)
Weight : 0.78 lbs / 0.355 kg
Construction : ABS
Front finish : Thin edged white grill (RAL9003)
Cut-out measurement : 128 x 80 mm
Built-in depth : 70 mm
Mounting & handling : 2 Screw quick-fixing mechanism
Colours : Black frame & white grill
Operating temperature : -20 °C ~ 60 °C
Accessories Included : Cut-out template
Accessories Included : GLM02/W - White grill (RAL9003)
Accessories Optional : GLM02/B - Black grill (RAL9005)
Accessories Optional : GLM02/P - Paintable grill
Accessories Optional : WMM20 - In-wall box for MERO2
Accessories Optional : WTR06 - 6W 100V line transformer

The missing link in speaker systems

These high quality loudspeaker connections are treated with an additional conductive Gold plating that ensures the best sound quality and creates the superior connection between the speaker and the audio cable. The spring clamp connector ensures a rapid installation time without the need of additional tools.

Allow your ears to spark your attention, not your eyes

Due to its slim design with a very thin border of only 1 mm and a limited grill depth which extrudes from the ceiling surface by only 3.2 mm, loudspeakers with SlimLine™ technology will become nearly invisible when mounted. This elegant and unobtrusive grill is held in place by means of powerful neodymium magnets, making assembly and disassembly very easy, while also providing an extremely reliable solution for keeping the grill in place during the complete lifetime of the loudspeaker.

*Note: AUDAC operates a policy of continuous development. AUDAC reserves the right to make changes and improvements to any of the products described on this website without prior notice. Specifications are subject to change without notice. Please refer to the manufacturer's web page for the most up to date specifications and product details www.audac.eu For the most up to date Software and Firmware visit www.audac.eu.
